7* 10W LED Beam Moving Head Light DMX Controlled LED Beam Moving Head Light

7*10W LED Beam Moving Head Light 2r, lamp, stage, disco, club TFT LCD , gorgeous interface and simple operationMini shape, quick and easy installation1. Packing ListØ 10W7Leds Moving Head Light 1 pcsØ User Manual 1 pcs2. Product Features&Osl

Featured Products

7*10W LED Beam Moving Head Light 2r, lamp, stage, disco, club


TFT LCD , gorgeous interface and simple operation
Mini shape, quick and easy installation

1. Packing List

Ø 10W7Leds Moving Head Light 1 pcs

Ø User Manual 1 pcs

2. Product Features

Ø TFT LCD , gorgeous interface and simple operation

Ø Chinese and English language switching , convenient to different user actions

Ø 65536 brightness level , true 16-bit dimming to eliminate the jitter problem of 8-bit dimming in low brightness , dimming softer

Ø Unlimited programming effects

Ø Special lighting effect

Ø No technical experience required

Ø Quick and easy installation

Ø Sealed for long, durable lifetime

Ø No bulbs to replace

Ø Indoor use in well temperate rooms

3. Specifications

3.1. Physical Specifications

Item No.:

RG-ML180BD-KEA8J10H15

Size:

250x165x270mm

Net Weight:

5.3Kg

Gross Weight:

6.3Kg

Beam:

13°

Color:

Black

Material:

Plastic and iron

Package Size:

370x330x225mm

Control mode:

Auto-run mode, DMX-512 mode, Sound active mode

DMX Channels:

11 / 15 CH

Protect Level:

IP20

Working Temperature:

-25°C~+35°C

3.2. Electrical Specifications

Max power consumption:

96W

Voltage:

AC 100-240V 50/60Hz

Service Life:

50000hour

Gray Level:

256

3.3. Other Specifications

Intelligent temperature control

Over heat protection ·


7*10W LED Beam Moving Head Light DMX Control LED Beam Moving Head Light
7*10W LED Beam Moving Head Light DMX Control LED Beam Moving Head Light
7*10W LED Beam Moving Head Light DMX Control LED Beam Moving Head Light7*10W LED Beam Moving Head Light DMX Control LED Beam Moving Head Light
ChannelValueFunction
CH10-255Total dimmer (0-100%)
CH20-255Red dimmer (0-100%)
CH30-255Green dimmer (0-100%)
CH40-255Blue dimmer (0-100%)
CH50-255White dimmer (0-100%)
CH60-255User custom color dimmer (0-100%)
CH70-255Pan (0-630°)
CH80-255Tilt (0-225°)
CH90-255Pan fine (16Bit)
CH100-255Tilt fine (16Bit)
CH110-255Pan&Tilt speed (from fast to slow)
CH120No strobe
1-255Strobe effect (from slow to fast)
&(CH1+CH2-CH6 ON)
CH130No function
1~25DMX handspike delay function     ON
26-50DMX handspike delay function     OFF
51-90Choose color by program (14CH)   ON
91-130Color pulse change effect
131-170Color jump change effect
171-210Color fade effect
211-250Auto-run mode
251-255Sound activate mode
CH140-255Speed adjust (14CH  91-210)
(from slow to fast)
0No function
1~20R255 G↑ B0 W0
21~40R↓ G255 B0 W0
41~60R0 G255 B↑ W0
61-80R0 G↓ B255 W0
81-100R↑ G0 B255 W0
101-120R255 G0 B↓ W0
121-140R255 G↑ B↑ W0
141-160R↓ G↓ B255 W0
161-170R255 G255 B255 W255
171-200R0 G0 B0 W0
201-205R242 G204 B5 W227
206-210R242 G215 B5 W227
211-215R255 G255 B50 W255
216-220R255 G255 B90 W255
221-225R255 G255 B118 W255
226-230R255 G255 B132 W255
231-235R255 G255 B151 W255
236-240R255 G255 B171 W255
241-245R255 G255 B185 W255
246-250R255 G255 B197 W255
251-255R255 G255 B234 W255
CH150-9IdCode invalid
10-19ID1
20-29ID2
30-39ID3
40-49ID4
50-59ID5
60-69ID6
70-79ID7
80-89ID8
90-99ID9
100-109ID10
110-119ID11
120-129ID12
130-139ID13
140-149ID14
150-159ID15
160-169ID16
170-179ID17
180-189ID18
190-199ID19
200-209ID20
210-219ID21
220-229ID22
230-239ID23
240-249ID24
250-255ID25
